DASCOM 28.B0E.6198 DC-240 Single-Sided Direct-to-Card Photo ID System
Details
DASCOM’s innovative technology in the DC-240 printer delivers exceptional value, allowing you to produce more cards at a cost-effective price. The DC-240 generates bright, high-resolution prints and includes all the necessary supplies, so you can start using it right out of the box. With built-in security features, this printer helps protect your organization’s identification process from potential threats. By ensuring the integrity of your ID cards, the DC-240 lets you focus on other critical areas of your business with confidence.
This particular SKU is a bundle that includes the printer, (1) YMCKO color ribbon, (100) CR80/30 white PVC cards, and Dascom CardEditor Software.
Direct to Card Printing Technology
This ID card printer uses advanced “direct-to-card” technology, where ink is directly diffused onto a blank PVC or composite card through a ribbon. The print head heats up and contacts the ribbon and card in a seamless, one-step process. Direct-to-card printers are highly efficient, making them ideal for high-volume printing environments. The method ensures reliable, consistent results, producing “edge-to-edge” prints that nearly cover the entire card, with only a narrow unprinted border. This technology offers a balance of speed, quality, and cost-effectiveness, making it a smart choice for organizations with regular security or visitor management needs.
Single-Sided ID Card Printing
This ID card printer is optimized for single-sided printing, focusing on efficiency and precision for projects where content is only needed on one side of the card. Its streamlined design makes it a cost-effective and straightforward solution for organizations that don’t require dual-sided printing capabilities. By dedicating its technology to one side at a time, the printer ensures consistent, high-quality output with each card, making it perfect for applications like employee IDs, membership cards, or visitor badges. Should your needs evolve to require dual-sided printing, additional passes, upgraded modules, or new equipment would be required to achieve that functionality.
Specifications
| Specification | Details |
|---|---|
| Print Method | Direct thermal technology |
| Resolution | Up to 300 x 600 dpi |
| Print Capability | Single Side only, Edge-to-Edge |
| Print Speed | 155 cards/hour (YMCKO) or 775 cards/hour (Monochrome K) |
| Lifetime Print Head | 15,000 Images |
| Interfaces | USB (2.0) |
| Card Thickness | 0.25 - 1.1 mm (10 - 50 mil) |
| Security Features | RFID ribbon, custom watermarks (BMP) |
| Card Loading | Auto card feeder for 100 cards (0.76 mm), Manual feed: single card |
| Card Output | 25 cards (front side) |
| Card Types | PVC, PET, PET-G, ABS, Teslin® |
| Card Size | 85.6 x 53.98 mm (ISO ID-1/CR-80) |
| Cleaning Set | Cleaning Card, Cleaning Roller |
| Physical Weight | 6.2 kg |
| Physical Size | 199 x 352 x 209 mm (W x D x H) |
| Power Voltage | Auto wide ranging, 100 - 240 V AC - 50/60 Hz |
| Environment | Printing: +15° to +35° C; 20 - 65% Humidity |
| Driver | Windows 8/8.1/10/11 |
| Warranty | For more details please contact your local dealer |
| Starter Kit | 100 PVC Cards, 1 YMCKO Ribbon (300 images), Card Editor Software |
