Fargo 55000 DTC4500e Single Sided

(0) No Reviews yet
SKU: 55000
MSRP: $3,299.00
$2,309.30 each

Add this item to get free shipping!

Details

With the Fargo DTC4500e plastic card printers and encoder, you get professional quality, full-color credentials. Designed for medium-to-large sized organizations, schools, and government institutions looking for reliable, long-term card printing and encoding solutions. The professional-grade 55000 DTC4500e plastic card printer and encoder withstands the daily demands of high-volume card printing. The versatility of the DTC4500e is unsurpassed. Driven by an extremely robust and reliable print engine, this high-volume printer delivers speed, power and versatility rolled into one. High-capacity ribbons enable the DTC4500e to print twice as many full-color cards as most printers before the ribbon has to be changed, providing continuous high-quality card printing and encoding.

Direct to Card Printing Technology

This ID card printer utilizes “direct-to-card” printing technology, which diffuses ink (in the form of a ribbon) directly to a blank PVC or Composite card material. The technology is literally named to describe the one step process in which the print head heats up then comes in direct contact with the ribbon and blank card substrate Direct to card printers and their simple printing process improve efficiency, and are ideal for high volume printing requirements. Card printing that utilizes direct contact with a fixed printhead results in “edge to edge” printing, which leaves a small unprinted border around the perimeter of the card.

300 dpi

This ID card printer prints with a resolution of 300 dpi (dots per inch) or 11.8 dpm (dots per millimeter).

Single Sided ID Card Printing

This ID card printer can print on only one side of a PVC or Composite card.

Specifications

HID Fargo 55000 Printing Capability
Single side printing

Printing Speeds (sec/card)
6 seconds (monochrome (K) single-sided card)
16 seconds (full-color (YMCKO) single-sided card)

Input Hopper Capacity
Dual Hoppers - 100 each (200 total)

Output Hopper Capacity
Up to 100 cards (.030 ̋ / .762 mm)

Card Reject Hopper
Up to 100 cards (.030 ̋ / .762 mm)  same-side input/output card hopper or lamination module required

Card Sizes Accepted
CR80 - standard PVC or PET (CR80 is the size of a standard credit card)
CR79 - adhesive-back (CR79 is slightly smaller than the size of a standard credit card)

Card Thickness Accepted
009 ̋ - .040 ̋ / 9 mil - 40 mil / .229 mm - 1.016 mm
Note: Mylar-backed thin cards are recommended

Interface
USB 2.0 & Ethernet with internal print server

Software Drivers
Microsoft® Windows® XP, Windows Server 2003 & 2008, Vista (32- & 64-bit), Windows 7 (32- & 64-bit), Windows 8 (32- & 64-bit)

HID Fargo Warranty
3 years on printer and printhead (unlimited pass with Ultracard™)

Fargo DTC4500e Weight & Dimensions
9 lbs (4.1 kg), 18.1'' x 9.8'' x 9.2'' (460mm x 249mm x 234mm)

HID Fargo Printer Includes
USB cable
US/International power cords
CD with printer drivers & user guide

Printer Options
Encoding:
ISO magnetic stripe (field-upgradeable)
Contact smart card encoding (factory ordered)
HID Prox reader (factory ordered)
iClass, MIFARE, ISO read/write encoder (factory ordered)

Same-side input/output hopper - field-installable
